Combination Implement Frames

Tractor Mounted Implement Frames

Implement Mounted Frames.png
  • Football
  • Hockey
  • Rugby
  • Cricket
  • Golf
  • Local Authority

Single pass maintenance system which accepts a variety of implements for use on both turf and hard porous surfaces.

Up to four operations can be carried out simultaneously with this simple and versatile system.

All implements are fully interchangeable and independently adjustable to give the desired effect and can be raised out of use when not required.

Connects to any tractor with 3 point linkage and utility trucks with suitable frame.

  • Versatile - can be used on natural turf, synthetic turf and hard porous surfaces.
  • Fast - up to four operations carried out simultaneously
  • Agri-jacks allow implements to be used lightly or more aggressively as required
  • 183cm and 244cm working widths available
  • Quadraplay has carrying platform for hand tools, seed etc.
  • Connects to any tractor with 3-point linkage and utility trucks with suitable frame.
  • Robustly constructed and very low maintenance
  • Quadraplay frame suitable for 4 implements
  • Singleplay frame suitable for 1 implement
  • Twinplay frame suitable for 2 implements
  • Tri-play frame suitable for 3 implements

Specification

Tractor Mounted Implement Frames

  • SpecificationSingleplayTwinplayTri-playQuadraplay
    Implements

    frame for 1 implement

    frame for 2 implements

    frame for 3 implements

    frame for 4 implements

    Code

    FS0870

    FS1237

    FS1236

    FS0758

  • Spiker Slitter.jpg

    Spiker Slitter

    Fast method of surface aeration allowing air and water to percolate into the root zone. Ideal for use during the playing season and before fertilizer applications and irrigation.

    1.2m - FS0561
    1.8m - FS0764
    2.4m - FS0774


    Rolaspike

    Ideal for surface aeration during the playing season allowing water and air into the root zone and integrating fertilizer into the surface. Also useful as part of an overseeding programme.

    1.2m - FS1271
    1.8m - FS1169
    2.4m - FS1267

    Straight Brush.jpg

    Straight Brush

    Used for standing grasses up, removing excess dew, enhancing presentation and brushing in dressings. Ideal on natural grass and hard porous areas. Suitable for maintenance of synthetic surfaces.

    1.2m - FS0865B
    1.8m - FS0765B
    2.4m - FS0775B

    Zig Zag Brush.jpg

    Zig Zag Brush

    Angled brush sections increase the brushing intensity. Ideal for removing dew, standing grasses up, working in top dressing and improving presentation. Ideal on natural grass and hard porous areas. Suitable for maintenance of synthetic surfaces.

    1.8m - FS0869B
    2.4m - FS0516B


    Flexicomb

    Ideal for standing up grasses and grooming, the easily adjusted crossbar increases or decreases the Flexicombs intensity. Suitable for maintenance of synthetic surfaces.

    1.3m - FS1163
    1.8m - FS1134
    2.4m - FS1277

    Intermediate Rake.jpg

    Intermediate Rake

    4mm diameter tines. Ideal for regular use on hard porous surfaces, gravel paths and running tracks.

    1.2m - FS1270
    1.8m - FS0759
    2.4m - FS1268

    Tilth Rake.jpg

    Tilth Rake

    5.5mm diameter tines. Ideal for compacted hard porous surfaces, gravel paths and running tracks.

    1.2m - FS1269
    1.8m - FS0760
    2.4m - FS1266

    Spring Tine Grooming Rake.jpg

    Spring Tine Grooming Rake

    7mm diameter spring tines for grooming and raking. Ideal for standing grasses up to improve presentation and remove thatch, useful for creating a tilth on worn areas. Also suitable for use on hard porous surfaces. Suitable for maintenance of synthetic surfaces.

    1.2m - FS1148
    1.8m - FS0761
    2.4m - FS0771

    Fine Grooming Rake.jpg

    Fine Grooming Rake

    5mm diameter spring tines for grooming and raking. Ideal for standing grasses up to improve presentation and remove thatch, useful for creating a tilth on worn areas. Also suitable for use on hard porous surfaces. Suitable for maintenance of synthetic surfaces.

    1.2m - FS1272
    1.8m - FS1075
    2.4m - FS1076

    Levelling Lute.jpg

    Levelling Lute

    Ideal for levelling and grading hard porous surfaces.

    1.8m - FS0762
    2.4m - FS0772


    Roller

    Ideal for light rolling of all surfaces and enhancing presentation. Used on natural grass and hard porous areas.

    1.2m - FS0863
    1.8m - FS0763
    2.4m - FS0773

    Grader Plate.jpg

    Grader Plate

    Ideal for levelling greyhound tracks or other sand based surfaces leaving a lightly compacted polished finish.

    2.0m - FS1110
    2.4m - FS1109

  • Football, Hockey, Rugby | Cricket.jpg

    Football, Hockey, Rugby | Cricket

    • Quadraplay
    • Spiker Slitter
    • Fine Grooming Rake
    • Roller
    • Brush
    Greyhound Race Tracks.jpg

    Greyhound Race Tracks

    • Quadraplay
    • Fine Grooming Rake
    • Intermediate Rake
    • Grader Plate
    Football, Rugby | Golf.jpg

    Football, Rugby | Golf

    • Twinplay
    • Zig Zag Brush
    • Brush
    Football, Rugby | Golf 2.jpg

    Football, Rugby | Golf 2

    • Twinplay
    • Spiker Slitter
    • Brush
    Golf Combination.jpg

    Golf

    • Singleplay
    • Spiker Slitter
